Servo

The SparkFun Wireless Motor Driver Shield is designed to make connecting motors, sensors and other components to your Arduino-based project as fast and easy as possible. The heart of the Wireless Motor Driver Shield is the Toshiba TB6612FNG H-Bridge Motor Driver, which allows the shield to control two DC motors at once, both CW and….

The Robot Builder’s Shield makes building robots with Arduino easy. Directly plug up to 6 sensors and up to 6 servos in to dedicated connectors and drive 2 DC motors from the built in H-bridge, 1A/motor. Flip the power switch On and use the J1 jumper to transfer power from the battery to Arduino’s Vin….

Uses two 4017 decade counters to drive up to 16 servos using only 4 pins (digital pins 6 to 9) and as little as one 8-bit timer (Timer 2) in standard mode or two 16/8-bit timers (Timer 1 and Timer 2 for Duemilanove or Timer 3 for Mega) in high accuracy mode. It also includes….

Note: I have almost no data on this shield, and I can’t find a web page about it so I’m just linking straight to the maker for now. The name is also in dispute: the PCB clearly states “IdeaShield”, but the packaging says “Ideal shield”. I’m taking the PCB as the authoritative reference. Supports up….

This Prototyping shield breaks out all pins on the Arduino for prototyping use in an accessible way. All pins are available with screw terminals on either side of the shield, and digital pins D2 to D13 have been made accessible via servo headers. The shield features a power select header and long-tail header plugs so….

Full-featured motor control shield that will be able to power many simple to medium-complexity projects. 2 connections for 5V “hobby” servos connected to the Arduino’s high-resolution dedicated timer. 4 H-Bridges: L293D chipset provides 0.6A per bridge (1.2A peak) with thermal shutdown protection, internal kickback protection diodes. Can run motors on 4.5VDC to 36VDC. Up to….
